制造工艺 | 封装形式 | 型号 |
FZ系列Single Switch单开关 |
IGBT3-E3 | 62 mm | FZ400R17KE3 FZ600R17KE3 FZ600R17KE3_S4 |
IHM 130 mm |
FZ1600R17KE3 |
IGBT4-E4 | 62 mm | FZ600R17KE4 FZ400R17KE4 |
IHMB130 mm | FZ1200R17HE4 FZ1200R17HE4P |
IHMB190 mm | FZ1800R17HE4_B9 FZ2400R17HE4_B9 FZ2400R17HE4P_B9 FZ3600R17HE4 FZ3600R17HE4P |
IGBT4-P4 | IHMB130 mm |
FZ1200R17HP4 FZ1600R17HP4 FZ1200R17HP4_B2 FZ1600R17HP4_B2 FZ2400R17HP4 FZ1600R17HP4_B21 FZ2400R17HP4_B2 |
IHMB190 mm |
FZ1800R17HP4_B29 FZ2400R17HP4_B28 FZ1800R17HP4_B9 FZ2400R17HP4_B29 FZ2400R17HP4_B9 FZ3600R17HP4 FZ3600R17HP4_B2 |
FF系列Dual两单元 |
IGBT3-E3 | 62 mm | FF200R17KE3 FF300R17KE3 |
EconoDUAL 3 |
FF150R17ME3G FF300R17ME3 FF225R17ME3 FF450R17ME3 |
IHM 130 mm | FF600R17KE3_B2 FF1200R17KE3 FF800R17KE3 |
IGBT4-E4 | 62 mm |
FF150R17KE4 FF300R17KE4 FF200R17KE4 FF300R17KE4P FF400R17KE4 FF500R17KE4 |
EconoDUAL 3 |
FF225R17ME4 FF225R17ME4_B11 FF225R17ME4P FF225R17ME4P_B11 FF300R17ME4 FF300R17ME4P FF300R17ME4_B11
FF300R17ME4P_B11 FF450R17ME4 FF450R17ME4_B11 FF450R17ME4P FF450R17ME4P_B11 FF600R17ME4 FF600R17ME4_B11
FF600R17ME4P FF600R17ME4P_B11 |
PrimePACK2 |
FF650R17IE4DP_B2 FF450R17IE4 FF650R17IE4 FF650R17IE4P FF650R17IE4D_B2 FF650R17IE4V |
PrimePACK3 | FF1000R17IE4 FF1000R17IE4P FF1000R17IE4D_B2 FF1000R17IE4DP_B2 |
IGBT4-P4 | IHM 130 mm |
FF800R17KP4_B2 FF1200R17KP4_B2 |
PrimePACK3 | FF1400R17IP4 FF1400R17IP4P |
IGBT5-P5 | PrimePACK2 |
FF1200R17IP5 |
PrimePACK3+ | FF1500R17IP5 FF1800R17IP5 FF1800R17IP5P |
F4系列Fourpack四单元 |
IGBT4 | EconoDUAL3 | F4-100R17ME4_B11 F4-250R17ME4_B11 F4-150R17ME4_B11 |
EconoPACK3 |
F4-200R17N3E4 |
FS系列Sixrpack六单元 |
IGBT3-E3 | EconoPACK + B | FS150R17KE3G FS225R17KE3 FS300R17KE3 FS450R17KE3 |
EconoPACK 2 |
FS50R17KE3_B17 |
EconoPACK3 | FS75R17KE3 FS100R17KE3 |
IGBT4-E4 | EconoPACK + B | FS225R17KE4 FS300R17KE4 FS450R17KE4 |
EconoPACK+ D | FS225R17OE4 FS300R17OE4 FS450R17OE4 FS450R17OE4P FS500R17OE4D FS500R17OE4DP |
EconoPACK 3 |
FS100R17N3E4 FS100R17N3E4_B11 FS150R17N3E4 FS150R17N3E4_B11 IFS100R17N3E4P_B11 |
EconoPACK 4 | FS100R17PE4 FS150R17PE4 |
FP系列PIM Three Phase Input Rectifier功率集成模块(带三相整流桥) |
IGBT4-E4 | EconoPIM3 | FP75R1N37E4 FP75R17N3E4_B11 |
FD、DF系列Chopper 斩波结构 |
IGBT 3-E3 | IHM130mm |
FD600R17KE3_B2 FD1200R17KE3-K FD800R17KE3-K |
IGBT4-P4 | IHMB 130mm | FD1200R17HP4-K_B2 FD800R17HP4-K_B2 |
IHMB 190mm | FD1600_1200R17HP4-K_B2 FD1600_1200R17HP4_B2 |
IGBT4-E4 | PrimePACK2 | FD650R17IE4 DF650R17IE4 |
PrimePACK3 | DF1000R17IE4 DF1000R17IE4D_B2 DF1000R17IE4P FD1000R17IE4 FD1000R17IE4D_B2 |
Diode二极管 |
| 62mm |
BYM300B170DN2 DZ800S17KE3 BYM600A170DN2 |
| IHMB 130mm |
DD1200S17H4_B2 DD800S17H4_B2 |
| IHM 190mm |
DZ3600S17K3_B2 |
